型    号

MIP530

MIP531

MIP521A

  Package

DIP-7/ SO-8

DIP-7/ SO-8

DIP-7

Output Power

Open Flame

AC85-264V

- 3.0W

- 6.0W

- 10W

AC150-264V

- 4.2W

- 8.0W

- 19W

Control

PWM + Burst

ILIMIT

0.2A

0.35A

0.5A

Frequency

125kHz

100kHz

67kHz

Break down Voltage of Drain

700V

700V

800V

EMI

Frequency Jitter function

Protection

Function

Over Load

Auto-restart

Over temperature

Auto-restart

Over Voltage

Latch stop  with Bias windings

Latch stop

Terminals

Drain, Source,

VDD, FB

Drain, Source,

VDD, FB

Drain, Source,

VCC, VDD, FB

Efficiency (5V output)

73% (AC220V)

78% (AC220V)

80%(AC220V)

Power consumption

at no load (AC220V)

0mW (With Bias windings)

120mW (Without Bias windings)

30mW

Remark

Bias winding is not necessary.If Low standby power or OVP is needed, Bias winding is necessary.

Bias winding is necessary.
